Mitutoyo TM-A505B Toolmaker’s Microscope with Digimatic Micrometer Heads, MIT176-820A


Original price was: $6,410.00.Current price is: $6,217.70.


Mitutoyo TM-A505B (MIT176-820A) toolmaker’s microscope with digimatic micrometer heads.  X-Y stage with 2″ x 2″ travel, featuring:

  • 2x objective lens, NA 0.07, WD 2.638″ (67mm).  Optional 5x and 10x objectives are available.
  • Monocular 15x eyepiece, 13mm field of view, inclined 30° with built-in crossline reticle.  Erect image, adjustable diopter.
  • Eyepiece protractor measures angles quickly by turning protractor to align the crosshair reticle with the workpiece image.  Graduation 1°.  Protractor range = 360°.  Minimum reading by vernier 6″.
  • 30x total magnification
  • 6″x 6″ (152mm x 152mm) stage with x-y travel of 2″ x 2″ (50mm x 50mm).  Effective area of glass stage is 3.78″ x 3.78″ (96mm x 96mm)  Maximum workpiece load is 11 lbs (5kg).
  • Maximum workpiece height is 4.53″ (115mm).
  • Includes 2 digimatic micrometer heads for x-y measurement.  Digimatic micrometer heads switch between millimeters and inches.
  • Transmitted LED light, green filter, adjustable light intensity.  Reflected light is oblique single-source LED illuminator with stepless brightness adjustment.  This illuminator can be replaced with optional LED ringlight.
  • Track stand with coarse focusing.
  • Weight = 30.8 lbs. (14kg)
