Mitutoyo TM-A1005B Toolmakers’ Microscope MIT176-821A

Description

Mitutoyo TM-A1005B Digimatic Toolmakers’ Microscope MIT176-821A features digimatic micrometer heads, x-y stage with 4″ x 2″ travel, a 2x objective lens with NA 0.07″, WD 2.638″, an eyepiece protractor with 1°gradations and a 360° range.  Total magnification with supplied 2x lens is 30x.  Usable area of stage glass is 6.3″ x 8″.   Micrometer heads included; resolution of  .0005″/1µm; micrometer head travel range 2″/50mm.
